Description
- Brand Name: electric magic
- Condition: New
- Model Number: 30mW 532nm
- is_customized: Yes
- Type: Laser
Two Model,dimension is customizable,please leave a message to tell us which one you want,if not,Random shipments
Parameters Specification
| Dimension | Φ10×34mm |
| Material | Copper |
| Surface | Brassiness |
| Life | >5000 hours(Continual Output) |
| Output Wavelength | 532nm/±5nm |
| Output Power | ≤30mW |
| Range Distance | 500~10000M(will affect by environmental and weather) |
| Beam/width | Dot/Min≤1.0mm,10m distance<15mm |
| Diffusion Angle | Default 90 Dgree |
| Controller | APC |
| Operate Voltage | DC=2.8~3.5V |
| Operate Current | I<350mA |
| Operate Temperature | 15°~50° |
| Storage Temperature | -10°~60° |
Need to work long overtime laser heat sink or metal bracket, so the module surface temperature between -10 degrees to +50 degrees, beyond this temperature causes rapid aging laser range.
Red positive power supply, the black wire to the negative power.
Application:
1 Sighting device for orientation
2 Laser test tools
3 Concertricity positioning
4 Production of signal equipment
5 Use for DIY robots
Package Including:
1* Laser Head
1* Power Charge
