Description
3W White Light Laser Diode Module Laser Head light White Lighting Effect RGB Light Combining W3000-B TTL
- Brand Name: laserlands
- Certification: NONE
- Style: Mini
- Power: 3W
- Model Number: 11010018
- Voltage: 5V
- Occasion: Home Entertainment
| Wavelength | 520nm ±5nm/638±5nm/445±5nm |
| Output Power | >3000mw |
| TTL Output Power | >1KHz Operating Output Power =Continuous Power x 40% |
| Output Stability | ±5% |
| Shape | Dot |
| Safety Class | Class 4 |
| Spot Dimension @3M | Φ 4mm |
| Divergence | ≤2mrad |
| Input Voltage(Power Board) | DC 12V |
| LD Input Voltage | Red-3V/Green-5V/Blue-5V |
| LD Input Current | Red-850mA/Green-2000mA/Blue-1500mA |
| Modulation | TTL |
| TTL | >DC 2.0V |
| Operating Frequency | <30KHz |
| Analog Control Input Voltage | DC 0–12V |
| Analog Max Input Voltage | DC12V |
| Working temperature | -30°C ~ -40 °C |
| Warm-up Time | < 1min |
| Life | >10000 hours |
| Weight | 300g |
