YOHUIE 1W-10W laser cnc machine, Desktop DIY Violet Laser Engraving Machine Picture CNC Printer Support offline work
|
Control software
|
Laser GRBL
|
|
Construction
|
Aluminum + Acrylic
|
|
Working area
|
300*400 mm
|
|
Work accuracy
|
0.1mm
|
|
Stepper motor
|
42 stepper motor 1.3A/0.3N.m
|
|
Laser interface
|
12V PWM
|
|
Power supply
|
AC100-240V
|
|
Supported system
|
Windows XP/ Win 7/ Win 8/ Win10 Home
|
|
Laser (options)
|
1000mw/2500mw/5500mw /7000mw/10000mw
|
Product include:
1 x Laser Engraver(full sets of spare parts , shall be installed by buyer,with detailed Assembly Video )
1 x AC power adapter
1 x protective glasse
1 x AU-EU Conversion plug
1 x CD for software and Assembly video
1 x Offline controller
Product feature:
1, the maximum engraving area of 30 * 40CM
2,This product supports offline work, connects offline controllers, imports picture material, and runs offline controller directly.
3, mobile gantry table sculpture, carved objects does not limit the size of the height, can be placed directly on top of the work * (such as engraving directly on the desk desktop)
4, aluminum material + acrylic simultaneously produced on a more solid look tall
5, the software is easy to use, free upgrades. software support windows XP, WIN 7, WIN 8 ,WIN10
Product advantages:
1, the software adjusts the power, supports 1000mw/1600mw/2500mw/5500mw/7000mw/10000mw
2, fast replacement laser head design + up and down adjustable focal length design
3, the largest engraving area reaches 30*40CM
4, all aluminum material + thick acrylic production, the appearance is taller and more stable at the same time
5, the software is simple and easy to use, free upgrade for life.
6, dual motor design is lighter and more accurate
7, the height of the engraved object is unlimited, you can put it directly on the work * (such as directly on the table to engrave the desktop)
8. The whole machine is shipped. After receiving the goods, you only need to connect the data cable to the computer, connect the power supply, and install the driver to start using it.
Common problem:
1. Which material can I use for this machine?
Wood, plastic, paper, bamboo, horn, part of leather (wallet), plastic phone case, rubber stamp, photosensitive stamp, sponge, paper.
2. This laser engraving machine is not suitable for the following materials:
Metal (regardless of thickness), stone, ceramic, jewelry, reflective materials, colorless transparent materials, soft materials.
3. The software is very easy to use,If you need a software description, please leave your email and contact us, we will send it to you
