10600nm Best sale 3D dynamic focus co2 laser galvo scanner head / laser scanner galvanometer head for 800mm*800mm laser marking

$6,305.00

SKU: 3452136018651 Category:

Description

 Best Sale 30mm co2 laser 3D dynamic focusing galvo head for 10w 20w 30w 50w 100w co2 laser 10600nm glass tube

BL8230-3D-800 Galvo head for 3D marking large area 3d laser galvanometer scanner co2 galvo 3d head  dynamic focus galvo head 3d co2 galvanometer Best Sale 30mm 3D dynamic focus co2 laser galvo head/ galvanometer scanner for co2 marking laser 3d co2 galvanometer glass tube dynamic focusing galvanometer head for marking laser co2 laser headgalvo co2 laser

Product Description


Motor Specification

Working Temperature

0-45℃

Linearity

99.9%

Setting Time

≤1ms

Scale Drift

<40PPM/℃

Zero Drift

<15μRad./℃

Long-term Drift Over 8 Hours

<0.5mRad

RMS Current

3.5A

Peak Current

20A(Max)

Maximum Scan Angle

±15°

Storage Temperature

-10 to +60℃

Resolution

12μrad

Repeatability

8μrad

Input Aperture

7-8mm

Beam Displacement

       30mm

Weight

8.3kg

Frequency

≤500Hz




Additional information

Model Number

BL8230-3D-800 3D dynamic focusing co2 laser galvo head
