Description
- Model Number: 45*45cm Laser Engraving Machine
- Condition: New
- CNC or Not: CNC
- Function: Wood Router
- Usage: mini cnc laser
- Stepper Motor: 1.3A42 stepper motor, – double rail Y axis
- System Support: Win XP/7/8/10
- Support software include: weidiao master, GRBL. etc.
- Engraving Area: 45x45cm / 17.72 x 17.72inch (maximum)
- Engraving materials: bamboo, wood, paper, plastic, leather, etc.
- Supported Formats: jpg, bmp, svg, G-code
- Data interface: USB
- Power Input: AC100-240V
- Laser Quick Replace: Support
New A3 Pro 15W Laser Engraving Machine 45*45cm 500mw 2500mw 5500mw 15000mw Wood Router DIY Mini GRBL Laser stainless Engraving Machine
Features:
30X38cm ultra large engraving area,gantry shape design, no engraving height limitation.
Three stepper motor drive providing faster moving speed.
violet laser module with heat sink, high laser engraving power and long-term available.
can print any pictures easily
Specifications:
- Model:A3 Pro Mini DIY Laser Engraving Machine
- Wavelength:445nm
- Control panel: Mana SE
- Communication Port:MircoUSB
- Laser Quick Replace:Support
- Stepper Motor:1.3A42 stepper motor, – double rail Y axis
- Power Input:AC100-240V，50 / 60Hz
- System Support:Win XP/7/8/10
- Support software include: weidiao master, GRBL. etc.
- Support gray engraving, sketch route cutting, line scanning engraving, spot engraving.etc.
- Material:Stainless Steel and Acrylic
- Working Voltage:DC 12V
- Working Current:DC 4-5A
- Laser Power:without/500 MW / 2500 MW / 5500 MW
- Engraving Accuracy:0.01mm
- Engraving Area:30x40cm / 11.81 x 15.75inch (maximum)
- Engraved object height limitation :No Limitation
- Product weight: 3.4kg
- Package weight: 4.9kg
- Product size: 60 * 45 * 21cm(L*W*H)
- Packing size: 58 * 40 * 13cm(L*W*H)
- Engraving materials: bamboo, wood, paper, plastic, leather, etc.
- Unable to sculpt metal/aluminum/acrylic/glass, etc.
- Function:ideal for amateur laser engraving usage low-light
- positioning and freedom positioning functions.
Note:
1. the the laser update since 2018.08.20, 5500mw and 15000mw can cut 3mm light wood ( plywood and mdf not sure) and engraving on stainless steel.
2 .Due to the shipping will make the CD broken sometimes , after you make the order please leave the email box to me, I will send the manual and software to you!
Precautions:
1. Wear laser goggles to protect your eyes when using.
2. DIY laser kit is shipped from loose parts. It needs to be assembled by itself and must have certain hands-on ability and patience. We provide assembly instructions and study materials. Please do not shoot if you have poor hands-on ability. DIY returns should not be returned after installation. Thank you for your cooperation!
3. We upgraded the laser, some parts are different from the old version, you can see the description photo.
4. Please note that the laser is recommended to take a break every 30 minutes of operation and not to work continuously for a long time, which is beneficial to the life of the laser.
Product Display:
