Description
- Origin: CN(Origin)
- Item Type: Lighting Transformers
Without driving circuit, N-pin of laser diode, the housing is LD positive and PD negative
Wavelength 650nm
Output power 3.0-7.0mw
Voltage 2.1V
Current < 25mA
Working temperature – 10 – + 70 ℃
Beam diameter 5mm
Spot size< 10mm@25 rice
The light spot is nearly the full circle
It can be used for gun aiming, level instrument, range finder and other industrial products
