Description
780nm 3mw 5mw IR Laser Diode TO 9.0mm Can N Type 790nm DL-3030 SANYO LD Infrared
- Certification: RoHS
- Origin: CN(Origin)
- Item Type: Stage Lighting Effect
- Occasion: Home Entertainment
- Light Output: 3mW
- Operating Voltage: 1.9V
- Operating Current: 50mA
Features
1. Absolute maximum ratings：5mW (CW)
2. TO-can Φ9.0mm package
Electrical and Optical Characteristics(Tc=25℃)
Lasing Wavelength:780nm(±10nm)
Optical Output:3mW
Threshold Current:40mA
Operating Current:50mA
Operating Voltage:1.9V
Operating Temperature:-10 to +60℃
Beam Divergence(FWHM)
Parallel:10deg
Perpendicular:30deg
External dimensions(Unit : mm)
Pin Description
